PoE High Frequency Transformer
POE-530-5
The EP13 transformer is a versatile and high-performance transformer widely used in many electronic devices and appliances. It is designed to efficiently convert AC power to DC power, making it an essential component for power conversion systems.
The EP13 transformer is characterized by its small footprint and lightweight design, making it ideal for applications with limited space. It is built with high-quality ferrite cores and copper coils, providing excellent thermal stability, low core loss, and high magnetic permeability. The transformer's advanced design minimizes stray magnetic fields and reduces electromagnetic interference (EMI) for stable and reliable operation.
With multiple turn ratios spanning a wide range of voltage ratings and operating frequencies, the EP13 transformer is ideal for use in switch-mode power supplies, inverters, and other power conversion systems. It can also be easily customized to meet specific requirements for different applications.
The EP13 transformer is characterized by its small footprint and lightweight design, making it ideal for applications with limited space. It is built with high-quality ferrite cores and copper coils, providing excellent thermal stability, low core loss, and high magnetic permeability. The transformer's advanced design minimizes stray magnetic fields and reduces electromagnetic interference (EMI) for stable and reliable operation.
With multiple turn ratios spanning a wide range of voltage ratings and operating frequencies, the EP13 transformer is ideal for use in switch-mode power supplies, inverters, and other power conversion systems. It can also be easily customized to meet specific requirements for different applications.
minimum order
1 piece
Country of Origin
Shenzhen Guangzhou
Quantity
PoE High Frequency Transformer
- LINK-POWER EP13 PoE Low Voltage Power Adapter High Frequency Transformer
- Flyback transformer for PoE applications.
- Meets IEEE 802.3af/bt(PoE) Standards.
- Operates in condition mode with 7V-72V input.
- Very low power lose of core used with operation frequency up to 300KHz.
- Resistance to soldering heat Max three 40 second reflows at +250°C, parts cooled to room temperature between cycles.
- Moisture Sensitivity Level (MSL) 1 .
- Terminations RoHS tin-silver-copper over tin over nickel over phos bronze.Other terminations available at additional cost.
- Operating Temperature -40°C to +85°C.(Including coil temperature rise due to self-generated heat).
- Storage Temperature -40°C to +125°C.
Weight6.3 g.
